鏈徑 (mm) |
α≤45° 載荷(t) |
45＜α≤60° 載荷(t) |
吊環(huán)尺寸(mm) 內(nèi)寬x內(nèi)長X直徑 |
鏈條重量 (kg) |
|---|---|---|---|---|
| 6 | 2.1 | 1.5 | 80x150x20 | 0.79 |
| 8 | 3.1 | 2.2 | 90x160x24 | 1.38 |
| 10 | 5.2 | 3.7 | 100x190x28 | 2.20 |
| 12 | 7.3 | 5.2 | 100x190x28 | 3.10 |
| 14 | 10.5 | 7.5 | 120x230x34 | 4.13 |
| 16 | 12.6 | 9 | 135x250x38 | 5.63 |
| 18 | 16.8 | 12 | 140x270x42 | 6.85 |
| 20 | 21 | 15 | 160x310x46 | 8.60 |
| 22 | 25.2 | 18 | 180x330x52 | 10.20 |
| 24 | 29.4 | 21 | 180x330x52 | 12.78 |
| 26 | 35.7 | 25.5 | 180x330x56 | 14.87 |
| 30 | 46.2 | 33 | 210x410x62 | 19.60 |
| 34 | 60.9 | 43.5 | 240×410×76 | 22.7 |
